Stainless Steel 2 Inch Incremental Shaft Encoder

Model 802S Features

Industry standard Size 20 (2" diameter) stainless steel package
Flange and servo mounting
Resolutions up to 30,000 CPR
80 lb maximum axial and radial shaft loading
IP67 sealing available

download_blue Download Model 802S datasheet

Configure Model

Configure a 3D model of this encoder with the exact specifications for your application. Then download the files in almost any native format, and design it in to your application.

Configure 3D Model

Purchase Options

Model 802S Accu-Coder servo mount (S, U, T)

Model 802S Servo Mount (S, U, T)

3 x 120° 1.500" bolt circle
4 - 40 0.250" deep
1.181" female pilot (S) shown above
0.687" male pilot (U)
1.250" male pilot (T)
Can be used with servo clips

Model 802S Flange Mount (F, L, G)

2.060" square flange
1.181" female pilot (F) shown above
0.687" male pilot (L)
1.250" male pilot (G)
Outer holes: 4 x 90° 2.475" bolt circle
Inner holes: 4 x 90° 2.000" bolt circle

Model 802S Servo Mount (J)

2.500" servo mount
6 x 60° 1.875" bolt circle
10 - 32 0.30" deep
1.250" diameter boss
Can be used with servo clips

Model 802S Flange Mount (K)

2.500" square flange
4 x 90° 2.920" bolt circle
1.250" diameter boss

Model 802S Description

The Model 802S Accu-Coder® is a heavy duty, industry standard Size 20 (2.0" diameter) incremental shaft encoder specifically designed for harsh factory and plant floor environments. The Model 802S is available with a variety of flange and servo mounting styles, making it easy to use in a broad range of applications. Its heavy duty, double-shielded ball bearings are rated at 80 pounds maximum axial and radial shaft load, ensuring long operating life. This ultra-rugged, yet compact encoder is housed in a type 316 stainless steel enclosure, making it ideal for applications where contamination or exposure to caustic chemicals is a concern. The Model 802S provides the precise, reliable output you've come to expect from Accu-Coder®.
